WELDER/GENERATOR/AIR COMPRESSOR Petrol Multi-function Part No.: GSTMF200A Code 1

WELDER – GENERATOR – AIR COMPRESSOR Petrol Multi-function 3 in 1 Part No.: GSTMF200A

Code No.: 1

Part No.: GSTMF200A

Shipping weight & size : 320 kgs & 150*80*120 cm

Description :

Superior Quality – Unprecedented Functionality – Exceptional Value

The Millers Falls GSTMF200A multi-function machine is the perfect compact space saving piece of equipment ideal for a variety of mobile on-site applications requiring the use of a generator or welder or air compressor or any combination of the three.

Whether you are involved in equipment repair, construction and structural steel work, mobile maintenance work or want a serious piece of equipment around the home or farm the Millers Falls multi-function 3 in 1 is your machine.

The unit requires less fuel and simplifies equipment management compared to purchasing separate components.

This unit is powered by a genuine Kohler Industrial Cast Iron Bore electric start engine for ultimate performance, reliability and durability.

Featuring a 200 Amp DC Arc Welder a 5.6kVa Generator and 500 litre per minute Air Compressor with a Two Stage Twin Cylinder Cast Iron Pump for maximum longevity and a massive 175PSI pressure output.   The unit is mounted on twin 30 litre side by side air receivers for added stability.

Welding, using power tools or air powered equipment have never been easier. This is a serious piece of equipment for those who are serious about the work they do.

Welding Accessories Included :

• Welding Lead 8-meter 25 mm2 Cable with Twist Type 300 Amp Electrode Holder & Dinse Plug.
• Earth Lead 8-meter 25 mm2 Cable with 300 Amp Earth Clamp & Dinse Plug.
• Engine:

• Brand                                      : Kohler
• Type                                        : 4 stroke, OHV, air cooled, single cylinder
• Power                                      : 14hp
• Displacement                          : 429cc,
• RPM                                        : 3600
• Noise                                       : 87dBa
• Starting                                    : Electric with manual backup
• Fuel                                         : Unleaded petrol
• Fuel capacity                          : 6.8 litres
• Full Tank Run Time                : 3 hours at 50% load

• Welder:

• Current range                          : DC 50-170amp
• Welding Rod Size                   : 1.6 - 4mm
• Rated duty cycle                     : 150A/100%
• Operating voltage                   : DC 26volts

• Generator:

• Volts                                        : 240
• Maximum output                    : 5.6kVa (4.5kW)
• Rated Power kVa                   : 5.25
• Max Power kVa                      : 4.5
• Rated Power kW                    : 4.2
• Amps                                       : 17.5
• Freq                                         : 50HZ
• THD                                        : < 5%
• Power Factor                          : 0.8
• Phase                                      : SINGLE
• Power with Compressor ON  : 2.8 kVa
• Power with Compressor OFF : 5.25 kVa

• Air compressor:
• Displacement : 500L/min
• Air Receiver : 2 x 30 litre
• Maximum Pressure : 175 PSI
• 2 stage Pump RPM : 850

12 months warranty

Colour may vary
