DMX 11 – Channel RGY Laser Disco Light Part No.: SLG06 Code No.: 17

DMX 11 – Channe; RGY Laser Disco Light Part No.: SLG06 Code No.: 17

Code No.: 17

Part No.: SLG06

Shipping weight & size :

Description:

Features:

• 4 working modes: DMX, Sound Active, AUTO and Master-Slave Control for different applications
• LED Display DMX control: 11 Channel
• ARA: Auto Running Random Effect
• SRS: Sound Activated Random effect
• SLP: Slow Moving Patterns effect
• FAP: Fast Moving Patterns effect
• SOP: Sound Activated Moving Patterns Effect
• SLL: Slow Moving Lines effect
• FAL: Fast Moving Lines effect
• SOL: Sound Activated Moving Lines effect
• SLD: Slow Moving Dots effect
• FAD: Fast Moving Dots effect
• SOD: Sound Activated Moving Dots effect
• Key Switch: Turn the laser effect ON/OFF by key provided
• Digital LED Display Control Panel
• Interlock function: used to connect the optional emergency stopper. when you push this switch the laser effect will be blank-out immediately

Specifications:

• Laser Classification: Class 3B
• Green laser Medium: DPSS Nd: YVO4, 532nm
• Red Laser Medium: LD GaAIAs 650nm, typical
• Beam Diameter: <5mm at aperture
• Pulse Date: All pulses <4Hz (>0.25sec)
• Divergence (each beam): <2mrad
• Divergence (total light): <120 degrees
• Laser power: Red>80mW, Green>40mW
• Main Input: AC100-240V, 50/60Hz
• Fuse: 1.6A/250V Slow Blow(20mm Glasss)
• Rated Power: 25W
• Music Control: Internal microphone
• DMX Connnections: 3 pins XLR Male/Female
• DMX Channels: 11 channels
• Size: 250mm(L)x180mm(W)x120mm(H)
• Weight: 3kg

N.B.  Colour may vary
