PARKING LIFT – 2.7 ton full platform Compact Parking Lift Part No.: STL2.7HP Code No. 31
Code No.: 31
Part No.: STL2.7HP
Shipping weight & size : 700 kgs & 3800*720*820mm
Description:
FEATURES:
- Commercial grade design with powder coated finish
- Sharing post feature available
- Galvanized and corrugated platform
- Dual hydraulic lifting cylinders with direct drive
- Individual hydraulic power unit and control panel
- Specially designed control arm for operator to control the lift without being under the platform
- Synchronization chain assuring the lifting platform is balanced
- With 6 locking tabs, platforms can be stopped at different heights to fit for various vehicles and ceiling heights
- Safety
- Electric key switch and emergency stop button for security and safety
- Automatic shut-off if operator releases the key switch
- Dynamic mechanical locks and anti-falling device hold the platform in place
- Anti-slip corrugated deck, to protect both vehicle and driver from possible slip and damage
- Warranty
- 5 years (structure) + 1 year electrical, mechanical, hydraulics. Parts & labour
- Hydraulic overloading protection
- Certification
- Engineer Certified
- Design Registered with Worksafe
SPECIFICATIONS:
- Capacity2.7 Ton
- Lock Release Electronic Release
- Power240V or 3 Phase
- Lifting Height2100mm
- Overall Height3362mm
- Overall Width2511mm
- Drive Through Clearance2100mm
- Lifting Time50 Seconds
- Lowering Time35 Seconds
- Freight Dimensions
L 3800mm W 720mm H 820mm W 700KG
We also offer installation as well as Annual maintenance and servicing for your hoist
Measurements and colour are correct at the time of publishing, however are subject to change. If these are crucial to your facility or vehicle requirements it is essential for you to discuss your particular requirements with us prior to purchasing your new hoist.
N.B. Colour may vary
