LOG SPLITTER with 10HP Briggs & Stratton Engine Part No.: LS40BD-BS
Code No.: 1
Part No.: LS40BD-BS
Shipping weight & size : 315 kgs & 173*72*59 cm
Description :
The Millers Falls Black Diamond LS40BD-BS 40 Ton Manual Start Hydraulic Log / Wood Splitter with Genuine Briggs & Stratton Engine has been built to split more wood with much less effort than you would have thought possible.
Millers Falls Black Diamond Log Splitters have been manufactured with the compact, powerful and innovative features to give the best performance and rigorously tested to meet high quality standards specifically for the Australian market. They have been one of the top choices in Australian market for years due to their durability, reliability and safety functions.
Its powerful 40 Tons of splitting force and 200mm wear proof hardened cast steel splitting wedge (most comparable log splitters on the market have only 150-180mm wedges) gives the Black Diamond LS40BD-BS 40 Ton Manual Start Log Splitter the strength and ability to easily out-split other comparable log splitters on the market and the power to make short work of even the hardest of Australian hardwoods.
The Millers Falls Black Diamond LS40BD-BS 40 Ton Hydraulic Log Splitter operates in both a horizontal and vertical position which means that you can adapt it to the most comfortable operating position for you or split larger diameter logs safely on the ground. Your back will be eternally grateful.
Another important feature of the Millers Falls Black Diamond LS40BD-BS 40 Ton Log Splitter is the auto return control valve which automatically retracts the ram when you remove your hand from the lever so that you can load the next log with less time and effort.
The 2 stage, 11GPM gear pump and 127mm x 493mm hydraulic cylinder powered by the powerful 13 horsepower, OHV 4 stroke Briggs & Stratton petrol engine allows the splitter to build to maximum pressure at lightning speed taking even more time and effort out of the equation.
The large 16 inch pneumatic tyres, 50mm cast steel coupler on the drawbar and support leg mean that you can take your Millers Falls Black Diamond LS40BD-BS 40 Ton Manual Start Hydraulic Log / Wood Splitter to wherever the timber to be split is on your property easily rather than having to cart all the wood to the splitter.
Features and specifications:
- Brand: Millers Falls Black Diamond
- Model: LS40BD-BS
- Engine: Briggs & Stratton 13 horsepower, 4 stroke, OHV, air cooled
- Starting: Manual (recoil) start
- Hydraulic cylinder size: 127mm (5") diameter x 493mm (19.4") stroke
- Oil capacity: 10 litres
- Gear pump : 2 stage 11GPM
- Automatic return control valve
- Maximum splitting force: 40 ton
- Wedge height: 8” (203mm)
- Split and return cycle time: 18 seconds
- Maximum log length: 24” (610mm)
- Working position: Horizontal and vertical
- Wheels and tyres: 16” x 6.5” pneumatic (overall diameter including tyres) with mudguards and rear reflectors
- Coupler: 50mm cast steel with safety chains
- Maximum recommended towing speed: 72 km/h Not to be towed on public roads
- Package dimensions: 173cm x 72cm x 59cm
- Package weight: 315kg
- 12 months warranty
- Colour may vary
